Name: Tungaloy 6848490 | VBE060L04.0-BG-04S04 AH725 6.00mm Diameter x 8.50mm Functional Length x 4.00mm Depth of Cut x 2.99mm Radius TiAlN Coated Carbide Ball End Mill Head
Brand: Tungaloy
SKU: 23157435
Availability: InStock

Tungaloy 6848490 | VBE060L04.0-BG-04S04 AH725 6.00mm Diameter x 8.50mm Functional Length x 4.00mm Depth of Cut x 2.99mm Radius TiAlN Coated Carbide Ball End Mill Head

$79.40 $65.90

(You save $13.50)

interval quantity:

SKU:

23157435

UPC:

Weight:

1.23 LBS

Minimum Purchase:

2 units

Shipping:

Free Shipping

Features
Reviews
Other Details

Ball, 4 flutes, roughing-finishing, helix cutting edge.

Product Specifications

Manufacturer Part Number	6848490
Cutting Diameter Maximum (mm)	6mm
Cutting Diameter (mm)	6mm
Depth of Cut Maximum (mm)	4mm
Functional Length (mm)	8.5mm
Corner Radius (mm)	2.99mm
Grade	AH725
Flute Helix Angle (Degree)	38 Degree
Number of Flutes	4
Body Material	Carbide
Coating	TiAlN
Cutting Edge Material	Carbide
Tool Type	Solid Ball Nose
Applicable Material	Steel, Stainless Steel, Cast Iron, Hi Temp Alloys
Application	Profile Milling
