Drill tubes - STS system - outer single start thread connection. please indicate the length (OAL) when ordering.
Product Specifications
| Cutting Diameter Maximum (mm) | 13.9 mm |
| Cutting Diameter Minimum (mm.) | 13.5 mm |
| Flange Diameter (mm) | 20 mm |
| Overall Length (mm) | 173.40mm |
| Application | BTA system |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.5472"
Minimum Cutting Diameter (Decimal Inch):
0.5315"
Flange Diameter (Decimal Inch):
0.7870"
Body Material:
Steel
Overall Length (Decimal Inch):
6.8270"
Point Length (Decimal Inch):
0.0810"
Shank Length (Decimal Inch):
1.8900"
Usable Length (Decimal Inch):
4.3700"
interval quantity:
1
