Square, 3 flutes, roughing-finishing, for non-ferrous metal, general.
Product Specifications
| Manufacturer Part Number | 6863908 |
| Cutting Diameter Maximum (Inch) | 3/4" |
| Cutting Diameter (Inch) | 3/4" |
| Depth of Cut Maximum (Inch) | 0.47" |
| Functional Length (Inch) | 1" |
| Corner Radius (Inch) | 1/8" |
| Maximum Feed per Tooth (fz) | 0.0067"/tooth |
| Grade | KS15F |
| Flute Helix Angle (Degree) | 45 Degree |
| Number of Flutes | 3 |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Body Material | Carbide |
| Cutting Edge Material | Carbide |
| Tool Type | Solid Carbide Center Cutting Endmills 90 |
| Applicable Material | Non Ferrous Metals |
| Application | Shoulder Milling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
Tungaloy
Maximum Cutting Diameter (Inch):
3/4"
Corner Radius (Inch):
1/8"
Finish/Coating:
Uncoated
Body Material:
Carbide
Grade:
KS15F
Maximum Depth of Cut (Decimal Inch):
0.4700"
Number of Flutes:
3
interval quantity:
2
