| Manufacturer Part Number | 6944477 |
| Corner Radius (Decimal Inch) | 0.016" |
| Cutting Edge Length (Decimal Inch) | 0.508" |
| Cutting Edge Effective Length (Decimal Inch) | 0.476" |
| Maximum Depth of Cut (Decimal Inch) | 0.020" |
| Minimum Depth of Cut (Decimal Inch) | 0.004" |
| Inscribed Circle Diameter (Inch) | 1/2" |
| Insert Thickness (Decimal Inch) | 0.187" |
| Chip Breaker Type | TF |
| Fixing Hole Diameter (Deciaml Inch) | 0.203" |
| Cutting Direction | Neutral |
| Grade | T9225 |
| Applicable Material | Steel, Stainless Steel, Cast Iron |
| Cutting Edge Material | Carbide |
| Body Material | Carbide |
| Coating | Ti-compound+Al2O3+TiN |
| Product Type | Turning Insert |
