Product Specifications
| Manufacturer Part Number | V618225-X |
| Drill Diameter (Decimal Inch) | 0.422" |
| Drill Diameter (mm) | 10.72mm |
| Drill Length (Decimal Inch) | 1.266" |
| Drill Length (mm) | 32.15mm |
| Number of Flutes | 2 |
| Flute Length (mm) | 43.28mm |
| Flute Length (Decimal Inch) | 1.704" |
| End Length (mm) | 1.95mm |
| Shank Diameter (mm) | 12.00mm |
| LOC Multiple | (3x) |
| Overall Length (mm) | 100.00mm |
| Coating | Val-Max X |
| Point Angle | 140 Degree |
| Product Type | High Performance Pilot Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Valor
Drill Point Angle:
140 Degree
Flute Length (Inch):
1-19/27"
Flute Length (Decimal Inch):
1.7040"
Flute Length (mm):
43.28mm
Overall Length (Inch):
3-15/16"
Overall Length (Decimal Inch):
3.9400"
Overall Length (mm):
100.00mm
Finish/Coating:
Val-Max X
Interval quantity:
1
