| Manufacturer Part Number | 0231ATF |
| Drill Bit Size (Inch) | 23/64" |
| Drill Bit Size (Decimal Inch) | 0.359" |
| Drill Bit Size (mm) | 9.13mm |
| Shank Diameter (Inch) | 23/64" |
| Shank Diameter (Decimal Inch) | 0.359" |
| Shank Diameter (mm) | 9.13mm |
| Length of Cut (Inch) | 2-9/32" |
| Length of Cut (Decimal Inch) | 2.281" |
| Length of Cut (mm) | 57.94mm |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.000" |
| Overall Length (mm) | 101.60mm |
| Point Length (Decimal Inch) | 0.065" |
| Point Length (mm) | 1.66mm |
| Drill Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 2 |
| Length / Diameter | 3 |
| Shank Tolerance | h6 |
| Coating | TiAlN |
| Material | Carbide |
| Series | DH414 |
| Hole Tolerance | +0-.00087 |
| Application | P |
| Cutting Direction | Right Hand |
| Product Type | Dream Drill Bit |
