| Manufacturer Part Number | 22002401 |
| Inscribed Circle (Decimal Inch) | 0.500" |
| Inscribed Circle (Inch) | 1/2" |
| Inscribed Circle (mm) | 12.70mm |
| Thickness (Decimal Inch) | 0.187" |
| Thickness (Inch) | 3/16" |
| Thickness (mm) | 4.76mm |
| Corner Radius (Decimal Inch) | 0.031" |
| Corner Radius (Inch) | 1/32" |
| Corner Radius (mm) | 0.80mm |
| Chipbreaker Application | Roughing and Heavy interrupted cut |
| Grade | YG3115 |
| Material | Carbide |
| Coating Process | CVD |
| Sqaure Size (Decimal Inch) | TiCN-Al2O3 |
| Cutting Edge Count | 8 |
| Shape | Square |
| Product Type | Turning Negative Insert |
