YG1 22002510 | 0.375" Inscribed Circle x 0.187" Thickness x 0.007" Radius x 0.622" Edge Length x 5 Degree Wiper Edge Clearence Angle 2 Edge Count TiCN-Al2O3 Coated Carbide Turning Positive Insert

$22.13 $14.94
(You save $7.19)
Brand:
YG1
Inscribed Circle (Decimal Inch):
0.3750"
Inscribed Circle (Inch):
3/8"
Inscribed Circle (mm):
9.53mm
Thickness:
0.1870"
Thickness (Inch):
3/16"""
Thickness (mm):
4.76mm
Corner Radius (Decimal Inch):
0.0070"
Material:
Carbide
interval quantity:
10
SKU:
25292865
UPC:
Weight:
1.23 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
YG1 22002510 | 0.375" Inscribed Circle x 0.187" Thickness x 0.007" Radius x 0.622" Edge Length x 5 Degree Wiper Edge Clearence Angle 2 Edge Count TiCN-Al2O3 Coated Carbide Turning Positive Insert

Product Specifications
Manufacturer Part Number22002510
Inscribed Circle (Decimal Inch)0.375"
Inscribed Circle (Inch)3/8"
Inscribed Circle (mm)9.53mm
Thickness (Decimal Inch)0.187"
Thickness (Inch)3/16"
Thickness (mm)4.76mm
Corner Radius (Decimal Inch)0.007"
Corner Radius (mm)0.20mm
Edge Length (Decimal Inch)0.622"
Edge Length (Inch)51/82"
Edge Length (mm)15.80mm
Chipbreaker ApplicationStainless Steel Finishing
Wiper Edge Clearance Angle5 Degree
GradeYG2025
MaterialCarbide
Coating ProcessCVD
Sqaure Size (Decimal Inch)TiCN-Al2O3
Cutting Edge Count2
ShapeRhombic 35°
Product TypeTurning Positive Insert
