Product Specifications
| EDP Number | 29020 |
| Diameter (Decimal Inch) | 0.5000" |
| Diameter (Inch) | 1/2" |
| Diameter (mm) | 12.70mm |
| Shank Diameter (Decimal Inch) | 0.7500" |
| Shank Diameter (Inch) | 3/4" |
| Shank Diameter (mm) | 19.05mm |
| Length of Cut (Decimal Inch) | 1.5000" |
| Length of Cut (Inch) | 1-1/2" |
| Length of Cut (mm) | 38.10mm |
| Overall Length (Decimal Inch) | 3.8750" |
| Overall Length (Inch) | 3-7/8" |
| Overall Length (mm) | 98.43mm |
| Round Radius (Decimal Inch) | 0.5000" |
| Round Radius (Inch) | 1/2" |
| Round Radius (mm) | 12.70mm |
| Number of Flutes | 4 |
| Helix Angle (Degree) | 0 Degree |
| Material | HSS |
| Coating | Bright |
| Shank Style | Flat |
| Cut Type | Corner Rounding |
| Corner Type | Corner Rounding |
| Cutting Direction | Right Hand |
| Application | P |
| Series | E1237 |
| Product Type | Corner Rounding End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Radius (Inch):
1/2"
Radius (Decimal Inch):
0.5000"
Radius (mm):
12.70mm
interval quantity:
1
