| Manufacturer Part Number | 56558TN |
| Diameter (Decimal Inch) | 0.1250" |
| Diameter (Inch) | 1/8" |
| Diameter (mm) | 3.18mm |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (mm) | 3.18mm |
| Length of Cut (Decimal Inch) | 0.5000" |
| Length of Cut (Inch) | 1/8" |
| Length of Cut (mm) | 12.70mm |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (mm) | 38.10mm |
| Corner Radius (Decimal Inch) | 0.0090" |
| Corner Radius (Inch) | 8/35" |
| Corner Radius (mm) | 0.23mm |
| Number of Flutes | 3 |
| Series | E5074 |
| Helix Angle (Degree) | 35 Degree |
| Coating | TiN |
| Material | Carbide |
| Shank Style | Plain |
| Cut Type | Center Cut |
| Length Type | Regular |
| Application | P,M |
| Cutting Direction | Right Hand |
| Product Type | Corner Radius End Mill |
