Product Specifications
| EDP Number | 61426 |
| Diameter (Decimal Inch) | 1.0000" |
| Diameter (Inch) | 1" |
| Diameter (mm) | 25.40mm |
| Shank Diameter (Decimal Inch) | 1.0000" |
| Shank Diameter (Inch) | 1" |
| Shank Diameter (mm) | 25.40mm |
| Length of Cut (Decimal Inch) | 3.0000" |
| Length of Cut (Inch) | 3" |
| Length of Cut (mm) | 76.20mm |
| Overall Length (Decimal Inch) | 5.5000" |
| Overall Length (Inch) | 5-1/2" |
| Overall Length (mm) | 139.70mm |
| Series | E2171 |
| Shank Style | Flat |
| Helix Angle | 30 Degree |
| Number of Flutes | 5 |
| Coating | Bright |
| Cut Type | End Cutting |
| Cutting Direction | Right |
| Type | Square End Mills |
| Application | P |
| Material | HSSCo8 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
1";Mill Diameter (Decimal Inch)=1.0000""
Mill Diameter (mm):
25.40mm
Number of Flutes:
5
Length of Cut (Inch):
3";Length of Cut (Decimal Inch)=3.0000""
Length of Cut (mm):
76.20mm
Shank Type:
Flat
Material:
HSSCo8
Finish/Coating:
Bright
Shank Diameter (Inch):
1";Shank Diameter (Decimal Inch)=1.0000""
Shank Diameter (mm):
25.40mm
Application:
End Cutting
Overall Length (Inch):
5-1/2";Overall Length (Decimal Inch)=5.5000""
Overall Length (mm):
139.70mm
Helix Angle:
30 Degree
