Product Specifications
| EDP Number | 71394CF |
| Diameter (Decimal Inch) | 0.8750" |
| Diameter (Inch) | 7/8" |
| Diameter (mm) | 22.23mm |
| Shank Diameter (Decimal Inch) | 0.8750" |
| Shank Diameter (Inch) | 7/8" |
| Shank Diameter (mm) | 22.23mm |
| Length of Cut (Decimal Inch) | 3.0000" |
| Length of Cut (Inch) | 3" |
| Length of Cut (mm) | 76.20mm |
| Overall Length (Decimal Inch) | 5.2500" |
| Overall Length (Inch) | 5-1/4" |
| Overall Length (mm) | 133.35mm |
| Series | E2077 |
| Shank Style | Flat |
| Helix Angle | 30 Degree |
| Number of Flutes | 5 |
| Coating | TiAIN F |
| Cut Type | End Cutting |
| Cutting Direction | Right |
| Type | Square End Mills |
| Application | P |
| Material | HSSCo8 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Length of Cut (Decimal Inch):
3.5000"
Length of Cut (Inch):
3-1/2"
Length of Cut (mm):
88.90mm
Overall Length (Decimal Inch):
5.2500"
Overall Length (mm):
133.35mm
Number of Flutes:
5
Helix Angle:
30 Degree
Finish/Coating:
TiAIN F
Material:
HSSCo8
Cutting Direction:
Right
interval quantity:
1
