Product Specifications
| Manufacturer Part Number | D1211054 |
| Diameter (Inch) | 27/32" |
| Diameter (Decimal Inch) | 0.8438" |
| Diameter (mm) | 21.43mm |
| Flute Length (Inch) | 6-1/8" |
| Flute Length (Decimal Inch) | 6.1250" |
| Flute Length (mm) | 155.58mm |
| Overall Length (Inch) | 10-3/4" |
| Overall Length (Decimal Inch) | 10.7500" |
| Overall Length (mm) | 273.05mm |
| Point Length (Decimal Inch) | 0.2535" |
| Point Length (mm) | 6.44mm |
| Number of Flutes | 2 |
| Morse Taper | 3 |
| Point Angle | 118 Degree |
| Helix Angle | 33 Degree |
| Coolant Through | No |
| Blank Standard | ANSI |
| Coating | Oxide |
| Material | HSS |
| Hole Tolerance | h8 |
| Application | P |
| Cutting Direction | Right |
| Series | D1211 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Drill Bit Size (Inch):
27/32"
Drill Bit Size (Decimal Inch):
0.8438"
Drill Bit Size (mm):
21.43mm
Shank Type:
Morse Taper
Drill Point Angle:
118 Degree
Flute Length (Inch):
6-1/8"
Flute Length (Decimal Inch):
6.1250"
Flute Length (mm):
155.58mm
Material:
HSS
Coating:
Oxide
interval quantity:
1
