Product Specifications
| Manufacturer Part Number | D1211059 |
| Diameter (Inch) | 59/64" |
| Diameter (Decimal Inch) | 0.9219" |
| Diameter (mm) | 23.42mm |
| Flute Length (Inch) | 6-1/8" |
| Flute Length (Decimal Inch) | 6.1250" |
| Flute Length (mm) | 155.58mm |
| Overall Length (Inch) | 10-3/4" |
| Overall Length (Decimal Inch) | 10.7500" |
| Overall Length (mm) | 273.05mm |
| Point Length (Decimal Inch) | 0.2770" |
| Point Length (mm) | 7.03mm |
| Number of Flutes | 2 |
| Morse Taper | 3 |
| Point Angle | 118 Degree |
| Helix Angle | 33 Degree |
| Coolant Through | No |
| Blank Standard | ANSI |
| Coating | Oxide |
| Material | HSS |
| Hole Tolerance | h8 |
| Application | P |
| Cutting Direction | Right |
| Series | D1211 |
