| Manufacturer Part Number | D1211102 |
| Diameter (Inch) | 1-1/32" |
| Diameter (Decimal Inch) | 1.0313" |
| Diameter (mm) | 26.19mm |
| Flute Length (Inch) | 6-1/2" |
| Flute Length (Decimal Inch) | 6.5000" |
| Flute Length (mm) | 165.10mm |
| Overall Length (Inch) | 11-1/8" |
| Overall Length (Decimal Inch) | 11.1250" |
| Overall Length (mm) | 282.58mm |
| Point Length (Decimal Inch) | 0.3098" |
| Point Length (mm) | 7.87mm |
| Number of Flutes | 2 |
| Morse Taper | 3 |
| Point Angle | 118 Degree |
| Helix Angle | 33 Degree |
| Coolant Through | No |
| Blank Standard | ANSI |
| Coating | Oxide |
| Material | HSS |
| Hole Tolerance | h8 |
| Application | P |
| Cutting Direction | Right |
| Series | D1211 |
