| Manufacturer Part Number | D4107165 |
| Size (Inch) | 13/20" |
| Size (Decimal Inch) | 0.650" |
| Size (mm) | 16.50mm |
| Shank Diameter (Inch) | 13/20" |
| Shank Diameter (Decimal Inch) | 0.650" |
| Shank Diameter (mm) | 16.50mm |
| Flute Length (Inch) | 2-25/69" |
| Flute Length (Decimal Inch) | 2.362" |
| Flute Length (mm) | 60.00mm |
| Overall Length (Inch) | 4-37/54" |
| Overall Length (Decimal Inch) | 4.685" |
| Overall Length (mm) | 119.00mm |
| Point Length (Decimal Inch) | 0.135" |
| Point Length (mm) | 3.42mm |
| Point Angle (Degree) | 135 Degree |
| Helix Angle (Degree) | 33 Degree |
| Number of Flutes | 2 |
| Series | D4107 |
| Blank Standard | DIN 1897 |
| Coating | TiN |
| Material | HSS |
| Hole Tolerance | h8 |
| Cutting Direction | Right Hand |
| Product Type | Screw Machine Length Drill Bit |
