Product Specifications
| Manufacturer Part Number | DB510087 |
| Cutting Diameter (Inch) | 25/73" |
| Cutting Diameter (Decimal Inch) | 0.342" |
| Cutting Diameter (mm) | 8.70mm |
| Shank Diameter (Inch) | 37/94" |
| Shank Diameter (Decimal Inch) | 0.394" |
| Shank Diameter (mm) | 10.00mm |
| Flute Length (Inch) | 2-2/5" |
| Flute Length (Decimal Inch) | 2.402" |
| Flute Length (mm) | 61.00mm |
| Overall Length (Inch) | 4-1/18" |
| Overall Length (Decimal Inch) | 4.055" |
| Overall Length (mm) | 103.00mm |
| Number of Flutes | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Cutting Direction | Right Hand |
| Coolant Pressure | 20 Bar |
| Coating | TiAlN |
| Material | Carbide |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Overall Length (Inch):
4-1/18"
Overall Length (Decimal Inch):
4.0550"
Overall Length (mm):
103.00mm
Point Angle:
140 Degree
Finish/Coating:
TiAlN
Material:
Carbide
interval quantity:
1
