| Manufacturer Part Number | DGE466209 |
| Diameter (Inch) | 3/11" |
| Diameter (Decimal Inch) | 0.2720" |
| Diameter (mm) | 6.91mm |
| Shank Diameter (Inch) | 3/11" |
| Shank Diameter (Decimal Inch) | 0.2720" |
| Shank Diameter (mm) | 6.91mm |
| Flute Length (Inch) | 2-13/64" |
| Flute Length (Decimal Inch) | 2.2031" |
| Flute Length (mm) | 55.96mm |
| Overall Length (Inch) | 4-19/64" |
| Overall Length (Decimal Inch) | 4.2969" |
| Overall Length (mm) | 109.14mm |
| Point Length (Decimal Inch) | 0.0817" |
| Point Length (mm) | 2.08mm |
| Number of Flute | 2 |
| Cutting Direction | Right Hand |
| Point Angle (Degree) | 118 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Blank Standard | DIN6537 |
| Hole Tolerance | +0-.00087 |
| Material | Carbide |
| Coating | DLC |
| Product Type | Coolant Fed Drill |
