| Manufacturer Part Number | DH453142 |
| Cutting Diameter (Inch) | 52/93" |
| Cutting Diameter (Decimal Inch) | 0.559" |
| Cutting Diameter (mm) | 14.20mm |
| Shank Diameter (Inch) | 17/27" |
| Shank Diameter (Decimal Inch) | 0.629" |
| Shank Diameter (mm) | 16.00mm |
| Flute Length (Inch) | 5-62/63" |
| Flute Length (Decimal Inch) | 5.984" |
| Flute Length (mm) | 152.00mm |
| Overall Length (Inch) | 8" |
| Overall Length (Decimal Inch) | 2.992" |
| Overall Length (mm) | 203.00mm |
| Point Length (Decimal Inch) | 0.101" |
| Point Length (mm) | 2.58mm |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | TiAIN |
| Product Type | Dream Drill |
