Product Specifications
| Manufacturer Part Number | DH453168 |
| Cutting Diameter (Inch) | 41/62" |
| Cutting Diameter (Decimal Inch) | 0.661" |
| Cutting Diameter (mm) | 16.80mm |
| Shank Diameter (Inch) | 17/24" |
| Shank Diameter (Decimal Inch) | 0.708" |
| Shank Diameter (mm) | 18.00mm |
| Flute Length (Inch) | 6-52/71" |
| Flute Length (Decimal Inch) | 6.732" |
| Flute Length (mm) | 171.00mm |
| Overall Length (Inch) | 8-57/77" |
| Overall Length (Decimal Inch) | 2.740" |
| Overall Length (mm) | 222.00mm |
| Point Length (Decimal Inch) | 0.120" |
| Point Length (mm) | 3.06mm |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | TiAIN |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
YG1
Drill Size (Decimal Inch):
0.6614"
Drill Size (mm):
16.80mm
Drill Point Angle:
140 Degree
Flute Length (Decimal Inch):
6.7323"
Flute Length (mm):
171.00mm
Overall Length (Decimal Inch):
8.7402"
Overall Length (mm):
222.00mm
Material:
Carbide
Finish/Coating:
TiAIN
Coolant Through:
Yes
Shank Diameter (Decimal Inch):
0.7087"
Shank Diameter (mm):
18.00mm
