Product Specifications
| Manufacturer Part Number | DH453176 |
| Cutting Diameter (Inch) | 9/13" |
| Cutting Diameter (Decimal Inch) | 0.692" |
| Cutting Diameter (mm) | 17.60mm |
| Shank Diameter (Inch) | 17/24" |
| Shank Diameter (Decimal Inch) | 0.708" |
| Shank Diameter (mm) | 18.00mm |
| Flute Length (Inch) | 6-52/71" |
| Flute Length (Decimal Inch) | 6.732" |
| Flute Length (mm) | 171.00mm |
| Overall Length (Inch) | 8-57/77" |
| Overall Length (Decimal Inch) | 2.740" |
| Overall Length (mm) | 222.00mm |
| Point Length (Decimal Inch) | 0.126" |
| Point Length (mm) | 3.20mm |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | TiAIN |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter (Decimal Inch):
0.6920"
Diameter (mm):
17.60mm
Shank Diameter (Decimal Inch):
0.7080"
Shank Diameter (mm):
18.00mm
Flute Length (Decimal Inch):
6.7320"
Flute Length (mm):
171.00mm
Point Length (Inch):
1/8"
Point Length (Decimal Inch):
0.1260"
Point Length (mm):
3.20mm
Helix Angle:
30 Degree
Coating:
TiAIN
Material:
Carbide
Cutting Direction:
Right Hand
Number of Flutes:
2
interval quantity:
1
