| Manufacturer Part Number | DH500090 |
| Diameter (Inch) | 28/79" |
| Diameter (Decimal Inch) | 0.3543" |
| Diameter (mm) | 9.00mm |
| Shank Diameter (Inch) | 37/94" |
| Shank Diameter (Decimal Inch) | 0.3937" |
| Shank Diameter (mm) | 10.00mm |
| Flute Length (Inch) | 2-21/86" |
| Flute Length (Decimal Inch) | 2.2441" |
| Flute Length (mm) | 57.00mm |
| Overall Length (Inch) | 4-2/15" |
| Overall Length (Decimal Inch) | 4.1339" |
| Overall Length (mm) | 105.00mm |
| Point Length (Decimal Inch) | 0.0645" |
| Point Length (mm) | 1.64mm |
| Number of Flute | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 15 Degree |
| Cutting Direction | Right Hand |
| Shank Tolerance | h6 |
| Hole Tolerance | h7 |
| Coolant Thru | Yes |
| Material | Carbide |
| Coating | TiAlN |
| Product Type | Coolant Fed Drill |
