Product Specifications
| EDP Number | DH510055 |
| Diameter (Decimal Inch) | 0.2165" |
| Diameter (Inch) | 21/97" |
| Diameter (mm) | 5.50mm |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (mm) | 6.00mm |
| Flute Length (Decimal Inch) | 2.8346" |
| Flute Length (Inch) | 2-5/6" |
| Flute Length (mm) | 72.00mm |
| Overall Length (Decimal Inch) | 5.0000" |
| Overall Length (Inch) | 5" |
| Overall Length (mm) | 127.00mm |
| Point Length (Decimal Inch) | 0.0394" |
| Point Length (mm) | 1.00mm |
| Number of Flutes | 2 |
| Series | DH510 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Length/Diameter | 10xD |
| Shank Tolerance | h6 |
| Hole Tolerance | h7 |
| Coating | TiAlN |
| Material | Carbide |
| Coolant Pressure | 20 Bar |
| Coolant Through | Yes |
| Application | P |
| Cutting Direction | Right |
| Product Type | MQL Dream Drill |
