| Manufacturer Part Number | DHM25071 |
| Diameter (Decimal Inch) | 0.2795" |
| Diameter (Inch) | 26/93" |
| Diameter (mm) | 7.10mm |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (mm) | 8.00mm |
| Flute Length (Decimal Inch) | 8.3071" |
| Flute Length (Inch) | 8-4/13" |
| Flute Length (mm) | 211.00mm |
| Overall Length (Decimal Inch) | 9.8819" |
| Overall Length (Inch) | 9-15/17" |
| Overall Length (mm) | 251.00mm |
| Point Length (Decimal Inch) | 0.0509" |
| Point Length (mm) | 1.29mm |
| Number of Flutes | 2 |
| Series | DHM25 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Length/Diameter | 25xD |
| Shank Tolerance | h6 |
| Hole Tolerance | h7 |
| Coating | TiAlN |
| Material | Carbide |
| Coolant Pressure | 45 Bar |
| Coolant Through | Yes |
| Application | P |
| Cutting Direction | Right |
| Product Type | MQL Dream Drill |
