Product Specifications
| # Manufacturer Number | DLGP195027 |
| Diameter (Decimal Inch) | 0.1063" |
| Diameter (Inch) | 5/47" |
| Diameter (mm) | 2.70mm |
| Shank Diameter (Decimal Inch) | 0.1063" |
| Shank Diameter (Inch) | 5/47" |
| Overall Length (Decimal Inch) | 2.4016" |
| Overall Length (Inch) | 2-2/5" |
| Overall Length (mm) | 61.00mm |
| Point Length (Decimal Inch) | 0.0220" |
| Point Length (mm) | 0.56mm |
| Point Angle (Degree) | 135 Degree |
| Helix Angle (Degree) | 33 Degree |
| Number of Flute | 2 |
| Coating | TiN |
| Material | HSS Co5 |
| Cutting Direction | Right |
| Hole Tolerance | h8 |
| Product Type | Jobber Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Drill Point Angle:
135 Degree
Overall Length (Inch):
2-2/5";Overall Length (Decimal Inch)=2.4016""
Overall Length (mm):
61.00mm
Cutting Direction:
Right
Material:
HSS Co5
Finish/Coating:
TiN
