| Manufacturer Part Number | DPP447042 |
| Diameter (Inch) | 1/6" |
| Diameter (Decimal Inch) | 0.1654" |
| Diameter (mm) | 4.20mm |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (mm) | 6.00mm |
| Flute Length (Inch) | 37/47" |
| Flute Length (Decimal Inch) | 0.7874" |
| Flute Length (mm) | 20.00mm |
| Overall Length (Inch) | 2-25/69" |
| Overall Length (Decimal Inch) | 2.3622" |
| Overall Length (mm) | 60.00mm |
| Number of Flutes | 2 |
| Point Angle | 180 Degree |
| Helix Angle | 20 Degree |
| Length/Diameter | 2 |
| Series | DPP447 |
| Shank Tolerance | h6 |
| Coolant Through | No |
| Coating | X-Coated |
| Material | Carbide |
| Hole Tolerance | h7 |
| Application | P,K |
| Cutting Direction | Right |
