| Manufacturer Part Number | DTX414015 |
| Cutting Diameter (Inch) | 15/64" |
| Cutting Diameter (Decimal Inch) | 0.234" |
| Cutting Diameter (mm) | 5.95mm |
| Shank Diameter (Inch) | 15/64" |
| Shank Diameter (Decimal Inch) | 0.234" |
| Shank Diameter (mm) | 5.95mm |
| Flute Length (Inch) | 1-1/8" |
| Flute Length (Decimal Inch) | 1.125" |
| Flute Length (mm) | 28.58mm |
| Overall Length (Inch) | 2-5/8" |
| Overall Length (Decimal Inch) | 2.625" |
| Overall Length (mm) | 66.68mm |
| Point Length (Decimal Inch) | 0.042" |
| Point Length (mm) | 1.08mm |
| Number of Flutes | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Cutting Direction | Right Hand |
| Coating | RCH Coated |
| Material | Carbide |
| Product Type | Dream Drill |
