Product Specifications
| Manufacturer Part Number | DTX712022 |
| Cutting Diameter (Inch) | 11/32" |
| Cutting Diameter (Decimal Inch) | 0.343" |
| Cutting Diameter (mm) | 8.73mm |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.375" |
| Shank Diameter (mm) | 9.53mm |
| Flute Length (Inch) | 2-27/32" |
| Flute Length (Decimal Inch) | 2.843" |
| Flute Length (mm) | 72.23mm |
| Overall Length (Inch) | 5" |
| Overall Length (Decimal Inch) | 5.000" |
| Overall Length (mm) | 127.00mm |
| Point Length (Decimal Inch) | 0.062" |
| Point Length (mm) | 1.59mm |
| Number of Flutes | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Cutting Direction | Right Hand |
| Coating | RCH Coated |
| Material | Carbide |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Cutting Diameter (Inch):
11/32"
Cutting Diameter (Decimal Inch):
0.3430"
Cutting Diameter (mm):
8.73mm
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Shank Diameter (mm):
9.53mm
Flute Length (Inch):
2-27/32"
Flute Length (Decimal Inch):
2.8430"
Flute Length (mm):
72.23mm
Overall Length (Inch):
5"
Overall Length (Decimal Inch):
5.0000"
Overall Length (mm):
127.00mm
Point Length (Inch):
1/16"
Point Length (Decimal Inch):
0.0620"
Point Length (mm):
1.59mm
Cutting Direction:
Right Hand
Shank Tolerance:
h6
Number of Flutes:
2
Finish/Coating:
RCH Coated
Material:
Carbide
