| Manufacturer Part Number | DTX722017 |
| Diameter (Inch) | 17/64" |
| Diameter (Decimal Inch) | 0.266" |
| Diameter (mm) | 6.75mm |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.313" |
| Shank Diameter (mm) | 11.11mm |
| Flute Length (Inch) | 2-13/64" |
| Flute Length (Decimal Inch) | 2.203" |
| Flute Length (mm) | 55.96mm |
| Overall Length (Inch) | 4-19/64" |
| Overall Length (Decimal Inch) | 4.297" |
| Overall Length (mm) | 109.14mm |
| Point Length (Decimal Inch) | 0.048" |
| Point Length (mm) | 1.23" |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Series | DTX722 |
| Coolant Pressure | 20 Bar |
| Coating | RCH |
| Material | Carbide |
| Cutting Direction | Right Hand |
| Product Type | Dream Drill |
