| Manufacturer Part Number | DTX722032 |
| Cutting Diameter (Inch) | 1/2" |
| Cutting Diameter (Decimal Inch) | 0.500" |
| Cutting Diameter (mm) | 12.70mm |
| Shank Diameter (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Shank Diameter (mm) | 12.70mm |
| Flute Length (Inch) | 4-3/32" |
| Flute Length (Decimal Inch) | 4.093" |
| Flute Length (mm) | 103.98mm |
| Overall Length (Inch) | 6-37/64" |
| Overall Length (Decimal Inch) | 6.578" |
| Overall Length (mm) | 167.08mm |
| Point Length (Decimal Inch) | 0.091" |
| Point Length (mm) | 2.31mm |
| Number of Flutes | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Cutting Direction | Right Hand |
| Coating | RCH Coated |
| Material | Carbide |
| Product Type | Dream Drill |
