| Manufacturer Part Number | E5G95930 |
| Mill Diameter (Inch) | 5/16" |
| Mill Diameter (Decimal Inch) | 0.313" |
| Mill Diameter (mm) | 7.94mm |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.313" |
| Shank Diameter (mm) | 7.94mm |
| Length of Cut (Inch) | 13/16" |
| Length of Cut (Decimal Inch) | 0.813" |
| Length of Cut (mm) | 20.64mm |
| Overall Length(Inch) | 3" |
| Overall Length (Decimal Inch) | 3.000" |
| Overall Length (mm) | 76.20mm |
| Shank Style | Plain |
| Helix Angle (Degree) | 37 Degree |
| Number of Flutes | 3 |
| Coating | Bright |
| Material | Carbide |
| Center Cut | Yes |
| Application | N |
| Cutting Direction | Right Hand |
| Series | E5G95 |
| Product Type | Square End Mill |
