Features
- High performance in machining aluminum and non-ferrous materials
- Special designed geometry with high rigidity cutting edge
- Improved surface roughness - cylindrical margin which is controlled tightly
- Excellent chip removal - higher rake angle, higher helix angle(45 Degree), bigger chip pocket
- Mirror face-excellent surface finish.
- Mill Diameter Tolerance: 0-.03"; Shank Diameter Tolerance: H6
Product Specifications
| Brand | YG1 |
| Mill Diameter (mm) | 8mm |
| Shank Diameter (mm) | 8mm |
| Length of Cut (mm) | 19mm |
| Overall Length (mm) | 63mm |
| Number of Flutes | 2 |
| Finish/Coating | TiCN |
| Tool Material | Carbide |
| Center Cutting (yes/no) | Yes |
| Single or Double End | Single |
| Cutting Direction | Right Hand |
| Flute Direction | Right |
| MPN | EG522080 |
| Helix Angle | 45 Degree |
| Series | E5522 |
| Country of Origin | Korea |
| End Type | Plain |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (mm):
8mm
Shank Diameter (mm):
8mm
Length of Cut (mm):
19mm
Overall Length (mm):
63mm
Number of Flutes:
2
Finish/Coating:
TiCN
Tool Material:
Carbide
Center Cutting:
Yes
Single or Double End:
Single
Cutting Direction:
Right Hand
Ships:
From Partner Facility
