Product Specifications
| EDP Number | EH527065 |
| Diameter (Decimal Inch) | 0.2600" |
| Diameter (Inch) | 11/43" |
| Diameter (mm) | 6.50mm |
| Shank Diameter (Decimal Inch) | 0.2559" |
| Shank Diameter (Inch) | 11/43" |
| Shank Diameter (mm) | 6.50mm |
| Length of Cut (Decimal Inch) | 0.5118" |
| Length of Cut (Inch) | 22/43" |
| Length of Cut (mm) | 13.00mm |
| Overall Length (Decimal Inch) | 2.3622" |
| Overall-Length-(Inch) | 2-25/69" |
| Overall Length (mm) | 60.00mm |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 2 |
| Cutting Direction | Right |
| Application | P |
| Shank Style | Plain |
| Series | EH527 |
| Coating | YG-Tylon F |
| Material | Carbide |
| Cut Type | Center |
| Length Type | Long |
| End Type | Single End |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter (Decimal Inch):
0.2559"
Diameter (Inch):
11/43"
Diameter (mm):
6.50mm
Shank Diameter (Decimal Inch):
0.2559"
Shank Diameter (Inch):
11/43"
Shank Diameter (mm):
6.50mm
Length of Cut (Decimal Inch):
0.5118"
Length of Cut (mm):
13.00mm
Overall Length (Decimal Inch):
2.3622"
Overall Length (mm):
60.00mm
Shank Style:
Plain
Helix Angle:
30 Degree
Material:
Carbide
Cut Type:
Center Cut
Cutting Direction:
Right
Number of Flutes:
2
interval quantity:
1
