Product Specifications
| EDP Number | EH527130 |
| Diameter (Decimal Inch) | 0.5100" |
| Diameter (Inch) | 22/43" |
| Diameter (mm) | 13.00mm |
| Shank Diameter (Decimal Inch) | 0.5118" |
| Shank Diameter (Inch) | 22/43" |
| Shank Diameter (mm) | 13.00mm |
| Length of Cut (Decimal Inch) | 0.8661" |
| Length of Cut (Inch) | 13/15" |
| Length of Cut (mm) | 22.00mm |
| Overall Length (Decimal Inch) | 3.2677" |
| Overall-Length-(Inch) | 3-19/71" |
| Overall Length (mm) | 83.00mm |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 2 |
| Cutting Direction | Right |
| Application | P |
| Shank Style | Plain |
| Series | EH527 |
| Coating | YG-Tylon F |
| Material | Carbide |
| Cut Type | Center |
| Length Type | Long |
| End Type | Single End |
| Product Type | Square End Mill |
