| Manufacturer Part Number | EH540080 |
| Diameter (Decimal Inch) | 0.3100" |
| Diameter (Inch) | 23/73" |
| Diameter (mm) | 8.00mm |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (mm) | 8.00mm |
| Length of Cut (Decimal Inch) | 0.7480" |
| Length of Cut (Inch) | 3/4" |
| Length of Cut (mm) | 19.00mm |
| Overall Length (Decimal Inch) | 2.4803" |
| Overall-Length-(Inch) | 2-12/25" |
| Overall Length (mm) | 63.00mm |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 4 |
| Cutting Direction | Right |
| Application | P |
| Shank Style | Plain |
| Series | EH540 |
| Coating | YG-Tylon F |
| Material | Carbide |
| Cut Type | Center |
| Length Type | Long |
| End Type | Single End |
| Product Type | Square End Mill |
