Product Specifications
| EDP Number | EH830250 |
| Diameter (Decimal Inch) | 0.9843" |
| Diameter (Inch) | 62/63" |
| Diameter (mm) | 25.00mm |
| Shank Diameter (Decimal Inch) | 0.9843" |
| Shank Diameter (Inch) | 62/63" |
| Shank Diameter (mm) | 25.00mm |
| Length of Cut (Decimal Inch) | 1.7717" |
| Length of Cut (Inch) | 1-71/8" |
| Length of Cut (mm) | 45.00mm |
| Overall Length (Decimal Inch) | 4.7244" |
| Overall Length (Inch) | 4-71/98" |
| Overall Length (mm) | 120.00mm |
| Number of Flutes | 4 |
| Series | EH830 |
| Helix Angle (Degree) | 50 Degree |
| Coating | TiAlN |
| Material | Carbide |
| Shank Style | Plain |
| Cut Type | Center Cut |
| Length Type | Long |
| Application | P,M,S |
| Cutting Direction | Right Hand |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Helix Angle:
50 Degree
Center Cutting:
Yes
Cutting Direction:
Right Hand
interval quantity:
1
