Product Specifications
| EDP Number | EH852070 |
| Diameter (Decimal Inch) | 0.2756" |
| Diameter (Inch) | 8/29" |
| Diameter (mm) | 7.00mm |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (mm) | 8.00mm |
| Length of Cut (Decimal Inch) | 0.3150" |
| Length of Cut (Inch) | 23/8" |
| Length of Cut (mm) | 8.00mm |
| Overall Length (Decimal Inch) | 2.2835" |
| Overall Length (Inch) | 2-17/60" |
| Overall Length (mm) | 58.00mm |
| Number of Flutes | 3 |
| Series | EH852 |
| Helix Angle (Degree) | 30 Degree |
| Coating | TiAlN |
| Material | Carbide |
| Shank Style | Plain |
| Cut Type | Center Cut |
| Length Type | Short |
| Application | P,M,S |
| Cutting Direction | Right Hand |
| Product Type | Roughing End Mill |
