Product Specifications
| EDP Number | EH921060 |
| Diameter (Decimal Inch) | 0.2362" |
| Diameter (Inch) | 13/55" |
| Diameter (mm) | 6.00mm |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Decimal Inch) | 0.6299" |
| Length of Cut (Inch) | 17/8" |
| Length of Cut (mm) | 16.00mm |
| Length Below Shank (Decimal Inch) | 0.7874" |
| Length Below Shank (Inch) | 37/47" |
| Length Below Shank (mm) | 20.00mm |
| Overall Length (Decimal Inch) | 2.2441" |
| Overall Length (Inch) | 2-21/86" |
| Overall Length (mm) | 57.00mm |
| Neck Diameter (Decimal Inch) | 0.2165" |
| Neck Diameter (Inch) | 21/97" |
| Neck Diameter (mm) | 5.50mm |
| Number of Flutes | 4 |
| Series | EH921 |
| Helix Angle (Degree) | 45 Degree |
| Coating | TiAlN |
| Material | Carbide |
| Shank Style | Plain |
| Cut Type | Center Cut |
| Length Type | Long |
| Application | P,M,S |
| Cutting Direction | Right Hand |
| Product Type | Roughing End Mill |
