Product Specifications
| EDP Number | EH921080 |
| Diameter (Decimal Inch) | 0.3150" |
| Diameter (Inch) | 23/73" |
| Diameter (mm) | 8.00mm |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (mm) | 8.00mm |
| Length of Cut (Decimal Inch) | 0.6299" |
| Length of Cut (Inch) | 17/8" |
| Length of Cut (mm) | 16.00mm |
| Length Below Shank (Decimal Inch) | 1.0236" |
| Length Below Shank (Inch) | 1-2/85" |
| Length Below Shank (mm) | 26.00mm |
| Overall Length (Decimal Inch) | 2.4803" |
| Overall Length (Inch) | 2-12/25" |
| Overall Length (mm) | 63.00mm |
| Neck Diameter (Decimal Inch) | 0.2953" |
| Neck Diameter (Inch) | 13/44" |
| Neck Diameter (mm) | 7.50mm |
| Number of Flutes | 4 |
| Series | EH921 |
| Helix Angle (Degree) | 45 Degree |
| Coating | TiAlN |
| Material | Carbide |
| Shank Style | Plain |
| Cut Type | Center Cut |
| Length Type | Long |
| Application | P,M,S |
| Cutting Direction | Right Hand |
| Product Type | Roughing End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Center Cutting:
Yes
interval quantity:
1
