| Manufacturer Part Number | EM817250 |
| Diameter (Decimal Inch) | 0.9800" |
| Diameter (Inch) | 62/63" |
| Diameter (mm) | 25.00mm |
| Shank Diameter (Decimal Inch) | 0.9843" |
| Shank Diameter (Inch) | 62/63" |
| Shank Diameter (mm) | 25.00mm |
| Length of Cut (Decimal Inch) | 2.9528" |
| Length of Cut (Inch) | 2-20/21" |
| Length of Cut (mm) | 75.00mm |
| Overall Length (Decimal Inch) | 5.5118" |
| Overall Length (mm) | 140.00mm |
| Overall Length (Inch) | 5-22/43" |
| Number of Flutes | 4 |
| Series | EM817 |
| Helix Angle (Degree) | 30 Degree |
| Shank Style | Plain |
| Coating | ALTiN |
| Cut Type | Center Cut |
| Length Type | Long |
| Material | Carbide |
| Cutting Direction | Right |
| Application | P |
| Produce Type | Square End Mill |
