Product Specifications
| Manufacturer Part Number | EMD46012 |
| Diameter (Inch) | 3/16" |
| Diameter (Decimal Inch) | 0.1875" |
| Diameter (mm) | 4.76mm |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (mm) | 4.76mm |
| Length of Cut (Inch) | 7/16" |
| Length of Cut (Decimal Inch) | 0.4375" |
| Length of Cut (mm) | 11.11mm |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (mm) | 50.80mm |
| Chamfer Size (Inch) | 1/250" |
| Chamfer Size (Decimal Inch) | 0.0040" |
| Chamfer Size (mm) | 0.10mm |
| Number of Flutes | 4 |
| Series | EMD46 |
| Shank Style | Plain |
| Helix Angle | Multiple |
| Coating | AlTiN |
| Material | Carbide |
| Cut Type | Center |
| Type | High Performance |
| Application | P,M,K |
| Cutting Direction | Right |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
3/16"
Mill Diameter (Decimal Inch):
0.1875"
Mill Diameter (mm):
4.76mm
Number of Flutes:
4
Length of Cut (Inch):
7/16"
Length of Cut (Decimal Inch):
0.4375"
Length of Cut (mm):
11.11mm
Shank Type:
11.11mm
Material:
Carbide
Coating:
AlTiN
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Shank Diameter (mm):
4.76mm
Application:
P,M,K
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Helix Angle:
Multiple
Cutting Direction:
Right
