Product Specifications
| Manufacturer Part Number | EMD58010 |
| Diameter (Inch) | 5/32" |
| Diameter (Decimal Inch) | 0.1563" |
| Diameter (mm) | 3.97mm |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (mm) | 4.76mm |
| Length of Cut (Inch) | 3/16" |
| Length of Cut (Decimal Inch) | 0.1875" |
| Length of Cut (mm) | 4.76mm |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (mm) | 50.80mm |
| Corner Radius (Inch) | 1/100" |
| Corner Radius (Decimal Inch) | 0.0100" |
| Corner Radius (mm) | 0.25mm |
| Number of Flutes | 4 |
| Series | EMD58 |
| Shank Style | Plain |
| Coating | AlTiN |
| Application | P,M,K |
| Cutting Direction | Right |
