Product Specifications
| Manufacturer Part Number | EMD59048 |
| Diameter (Inch) | 3/4" |
| Diameter (Decimal Inch) | 0.7500" |
| Diameter (mm) | 19.05mm |
| Shank Diameter (Inch) | 3/4" |
| Shank Diameter (Decimal Inch) | 0.7500" |
| Shank Diameter (mm) | 19.05mm |
| Length of Cut (Inch) | 3/4" |
| Length of Cut (Decimal Inch) | 0.7500" |
| Length of Cut (mm) | 19.05mm |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.0000" |
| Overall Length (mm) | 76.20mm |
| Corner Radius (Inch) | 2/57" |
| Corner Radius (Decimal Inch) | 0.0350" |
| Corner Radius (mm) | 0.89mm |
| Number of Flutes | 4 |
| Series | EMD59 |
| Shank Style | Flat |
| Coating | AlTiN |
| Application | P,M,K |
| Cutting Direction | Right |
