| Manufacturer Part Number | ESD02015205 |
| Diameter (Inch) | 1/17" |
| Diameter (Decimal Inch) | 0.0591" |
| Diameter (mm) | 1.50mm |
| Shank Diameter (Inch) | 3/19" |
| Shank Diameter (Decimal Inch) | 0.1575" |
| Shank Diameter (mm) | 4.00mm |
| Length of Cut (Inch) | 3/76" |
| Length of Cut (Decimal Inch) | 0.0394" |
| Length of Cut (mm) | 1.00mm |
| LBS (Inch) | 12/61" |
| LBS (Decimal Inch) | 0.1969" |
| LBS (mm) | 5.00mm |
| Overall Length (Inch) | 1-31/32" |
| Overall Length (Decimal Inch) | 1.9685" |
| Overall Length (mm) | 50.00mm |
| Corner Radius (Inch) | 1/127" |
| Corner Radius (Decimal Inch) | 0.0079" |
| Corner Radius (mm) | 0.20mm |
| Shank Style | Plain |
| Number of Flute | 2 |
| Material | CBN |
| Product Type | Corner Radius End Mill |
