Product Specifications
| # Manufacturer Number | G8A36045 |
| Diameter (Decimal Inch) | 0.1772" |
| Diameter (Inch) | 14/79" |
| Diameter (mm) | 4.50mm |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Decimal Inch) | 0.2362" |
| Length of Cut (Inch) | 13/55" |
| Length of Cut (mm) | 6.00mm |
| Overall Length (Decimal Inch) | 1.7717" |
| Overall-Length-(Inch) | 1-71/92" |
| Overall Length (mm) | 45.00mm |
| Corner Radius (Decimal Inch) | 0.0039" |
| Corner Radius (Inch) | 1/254" |
| Corner Radius (mm) | 0.10mm |
| LBS (Decimal Inch) | 0.3937" |
| LBS-(Inch) | 37/94" |
| LBS (mm) | 10.00mm |
| Neck (Decimal Inch) | 0.1713" |
| Neck (Inch) | 6/35" |
| Neck (mm) | 4.35mm |
| Helix Angle (Degree) | 30 Degree |
| Number of Flute | 2 |
| Coating | Blue |
| Material | Carbide |
| Cut Type | Center Cutting |
| Cutting Direction | Right |
| Shank Style | Plain |
| Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
14/79"
Mill Diameter (Decimal Inch):
0.1772"
Mill Diameter (mm):
4.50mm
Number of Flutes:
2
Corner Radius (Inch):
1/254"
Corner Radius (Decimal Inch):
0.0039"
Corner Radius (mm):
0.10mm
Length of Cut (Inch):
13/55"
Length of Cut (Decimal Inch):
0.2362"
Length of Cut (mm):
6.00mm
Shank Type:
Plain
Material:
Carbide
Finish/Coating:
Blue
Shank Diameter (Inch):
13/55"
Shank Diameter (Decimal Inch):
0.2362"
Shank Diameter (mm):
6.00mm
Application:
P,H
Overall Length (Inch):
1 71/92"
Overall Length (Decimal Inch):
1.7717"
Overall Length (mm):
45.00mm
Cutting Direction:
Right
