Product Specifications
| Manufacturer Part Number | G9I01007N |
| Mill Diameter (Inch) | 7/64" |
| Mill Diameter (Decimal Inch) | 0.1094" |
| Mill Diameter (mm) | 2.78mm |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (mm) | 3.18mm |
| Length of Cut (Inch) | 3/16" |
| Length of Cut (Decimal Inch) | 0.1875" |
| Length of Cut (mm) | 4.76mm |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall Length (mm) | 38.10mm |
| Ball Nose (Decimal Inch) | 0.0547" |
| Ball Nose (Inch) | 4/73" |
| Ball Nose (mm) | 1.39mm |
| Helix | 30 Degree |
| Series | G9I01 |
| Coated | X-Coating |
| Material | Carbide |
| Type | Ball Nose Double End |
| Corner Type | Ball Nose |
