YG1 GM812200 | 37/47" Diameter x 37/47" Shank x 1-1/2" LOC x 4-5/53" OAL 8 Flute Carbide Square End Mill

$232.87
Brand:
YG1
Mill Diameter (Inch):
37/47"
Mill Diameter (Decimal Inch):
0.7874"
Mill Diameter (mm):
20.00mm
Number of Flutes:
8
Length of Cut (Inch):
1-1/2"
Length of Cut (Decimal Inch):
1.4961"
Length of Cut (mm):
38.00mm
Material:
Carbide
Overall Length (Inch):
4-5/53"
Overall Length (Decimal Inch):
4.0945"
Overall Length (mm):
104.00mm
Shank Diameter (Inch):
37/47"
Shank Diameter (Decimal Inch):
0.7874"
Shank Diameter (mm):
20.00mm
SKU:
25176091
Weight:
1.23 LBS
Shipping:
Free Shipping
YG1 GM812200 | 37/47" Diameter x 37/47" Shank x 1-1/2" LOC x 4-5/53" OAL 8 Flute Carbide Square End Mill

Product Specifications
Manufacturer Part NumberGM812200
Mill Diameter (Inch)37/47"
Mill Diameter (Decimal Inch)0.7874"
Mill Diameter (mm)20.00mm
Shank Diameter (Inch)37/47"
Shank Diameter (Decimal Inch)0.7874"
Shank Diameter (mm)20.00mm
Length of Cut (Inch)1-1/2"
Length of Cut (Decimal Inch)1.4961"
Length of Cut (mm)38.00mm
Overall Length (Inch)4-5/53"
Overall Length (Decimal Inch)4.0945"
Overall Length (mm)104.00mm
Helix (Degree)45 Degree
Number of Flute8
Shank TypePlain
MaterialCarbide
Product TypeSquare End Mill

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
YG1
Mill Diameter (Inch):
37/47"
Mill Diameter (Decimal Inch):
0.7874"
Mill Diameter (mm):
20.00mm
Number of Flutes:
8
Length of Cut (Inch):
1-1/2"
Length of Cut (Decimal Inch):
1.4961"
Length of Cut (mm):
38.00mm
Material:
Carbide
Overall Length (Inch):
4-5/53"
Overall Length (Decimal Inch):
4.0945"
Overall Length (mm):
104.00mm
Shank Diameter (Inch):
37/47"
Shank Diameter (Decimal Inch):
0.7874"
Shank Diameter (mm):
20.00mm
