Product Specifications
| Manufacturer Part Number | GMF60918 |
| Diameter (Inch) | 43/91" |
| Diameter (Decimal Inch) | 0.4724" |
| Diameter (mm) | 12.00mm |
| Shank Diameter (Inch) | 43/91" |
| Shank Diameter (Decimal Inch) | 0.4724" |
| Shank Diameter (mm) | 12.00mm |
| Length of Cut (Inch) | 1-2/85" |
| Length of Cut (Decimal Inch) | 1.0236" |
| Length of Cut (mm) | 26.00mm |
| Overall Length (Inch) | 3-19/71" |
| Overall Length (Decimal Inch) | 3.2677" |
| Overall Length (mm) | 83.00mm |
| Number of Flutes | 4 |
| Helix Angle | Variable |
| Series | GMF60 |
| Shank Style | Plain |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Extended Length |
| Application | P, M, K, S |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Cutting Direction:
Right
interval quantity:
1
