| Manufacturer Part Number | GMF62917 |
| Diameter (Inch) | 13/55" |
| Diameter (Decimal Inch) | 0.2362" |
| Diameter (mm) | 6.00mm |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Inch) | 37/94" |
| Length of Cut (Decimal Inch) | 0.3937" |
| Length of Cut (mm) | 10.00mm |
| Overall Length (Inch) | 2-21/23" |
| Overall Length (Decimal Inch) | 2.9134" |
| Overall Length (mm) | 74.00mm |
| Corner Radius (Inch) | 3/76" |
| Corner Radius (Decimal Inch) | 0.0394" |
| Corner Radius (mm) | 1.00mm |
| Number of Flutes | 4 |
| Helix Angle | Variable |
| Series | GMF62 |
| Shank Style | Plain |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Extended Length |
| Application | P, M, K, S |
