Product Specifications
| Manufacturer Part Number | GMF63929 |
| Diameter (Inch) | 43/91" |
| Diameter (Decimal Inch) | 0.4724" |
| Diameter (mm) | 12.00mm |
| Shank Diameter (Inch) | 43/91" |
| Shank Diameter (Decimal Inch) | 0.4724" |
| Shank Diameter (mm) | 12.00mm |
| Length of Cut (Inch) | 17/27" |
| Length of Cut (Decimal Inch) | 0.6299" |
| Length of Cut (mm) | 16.00mm |
| Overall Length (Inch) | 3-19/71" |
| Overall Length (Decimal Inch) | 3.2677" |
| Overall Length (mm) | 83.00mm |
| Corner Radius (Inch) | 3/38" |
| Corner Radius (Decimal Inch) | 0.0787" |
| Corner Radius (mm) | 2.00mm |
| Number of Flutes | 4 |
| Helix Angle | Variable |
| Series | GMF63 |
| Shank Style | Flat |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Extended Length |
| Application | P, M, K, S |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter (Decimal Inch):
0.4724"
Diameter (Inch):
43/91"
Diameter (mm):
12.00mm
Shank Diameter (Decimal Inch):
0.4724"
Shank Diameter (Inch):
43/91"
Shank Diameter (mm):
12.00mm
Length of Cut (Decimal Inch):
0.6299"
Length of Cut (mm):
16.00mm
Overall Length (Decimal Inch):
3.2677"
Overall Length (Inch):
3-19/71"
Overall Length (mm):
83.00mm
Corner Radius (Decimal Inch):
0.0787"
Corner Radius (mm):
2.00mm
Number of Flutes:
4
Shank Style:
Flat
Finish/Coating:
Y-Coating
Material:
Carbide
Cut Type:
Center
Cutting Direction:
Right
interval quantity:
1
